防火阀设备

首页 > 产品系列 > 防火阀设备


正压送风口 框体生产线




功能描述Function description:

双伺服驱动,全自动化操作
Double servo motor,full automatic operation.
外框宽度Vent frame width:220(240)mm.
加工方式processing mode:L型/口字型/单片 L shape/口shape/sheet.
产量Output:500件外框/8小时 500 pieces frame/8 hours.
连续定单模式Continuous order production.
符合3C认证规范Meet 3C standard.


技术参数Technical data:
加工厚度Material thickness:1.5mm.
材质Material:镀锌板,低碳钢;Low carbon steel,Galvanized steel,Q235,etc.
卷料宽度Coil width:240mm.
成型速度Working speed:6~8M/Min.
电机功率Motor:28KW;
重量Weight:9000kg;

外形尺寸Dimension:11000 x 1200 x 1550。
